About ActCAD 2020 Software Software

ActCAD is a 2D Drafting and 3D Modeling (Partial) CAD software meant for Engineers, Architects and other technical consultants. ActCAD is a native DWG & DXF CAD software to create and edit drawings. ActCAD uses IntelliCAD engine, Open Design Alliance DWG/DXF Libraries, ACIS 3D Modeling Kernel and many other Technologies. In-addition, ActCAD has many add-on command, features and other Productivity Tools. ActCAD CAD Software includes many other tools like Block Libraries (in the domains of Civil, Mechanical, Electrical, Architectural, Structural, P &IDs etc.), Batch file converter, Units converter, PDF to DXF Converter, Image to DXF converter and many other productive tools. ActCAD supports many other file formats like dgn, STL, OBJ, 2D PDF, SVG and many other file formats. All dwg/dxf versions from very old R2.5 to latest 2018 are supported.

ActCAD interface is carefully designed for easy selection of commands without much difficulty. The interface and commands are very familiar for easy migration from other CAD Software. ActCAD has complete range of 2D Drafting & 3D Modeling tools along with editing options. Artisan Render is also included in ActCAD at no extra cost to create high quality renderings. ActCAD can be operated in both modern Ribbon Style Interface and Classic Drop Down menu Styles. The interface, aliases and commands can be completely customized as per your requirements. Unlimited work spaces are supported inside ActCAD.

ActCAD 2020 Software Key Benefits

Life Time Validity

ActCAD drawing Software offers Full LifeTime Validity after purchasing the ActCAD Software License. No need to pay annual subscriptions. Upgrades to future versions are optional.


ActCAD users can develop their custom programs to work inside ActCAD using .NET, SDS, LISP, DCL and C++ languages. API kit comes with many sample programs and solutions.


ActCAD is now available with Artisan Professional Rendering package at no extra cost. Available with many rendering features like Photo-realistic rendering, 360° viewing, lights, materials etc. available.

Many ADD-ON Features

ActCAD has many add-on features like Units converter, Open PDF to Edit, ActCAD converter, Raster to Vector, Block Library with over 5000 symbols etc.

Value For Money

ActCAD works on a collaborated development model with IntelliCAD & hence we offer our products at very low prices, which are perpetual and valid for life-time

Free Technical Support

ActCAD drawing software has a dedicated Technical Support team who is responsible to handle any technical queries and address the problems in a quick time frame.


ActCAD comes with a Block Library with over 5000 symbols in Civil, Mechanical, Electrical and other domains. Double click any symbol and insert into your drawing.

Self License Transfer

ActCAD drawing software offers Global Licensing on all its cad software versions. Licenses can be purchased any where and can be used anywhere in the World.

Easy Learning Curve

ActCAD is easy to learn and use. ActCAD incorporates a user interface, commands, icons and shortcuts similar to that used by the most popular CAD programs.

truecad software

ActCAD 2020 Software Product

* Click on Get Free Trial for Download links
* All licenses are perpetual and valid for life-time.


ActCAD 2020 Video

actcad intellicad 2020 video






Happy Users

ActCAD 2020 Highlights

All New user interface with modern Black Theme
IntelliCAD 9.2 & ODA 4.3 Libraries
Attach digital signatures to .dwg files and validate them
Command options are now clickable in the command bar
Introduced a Start Page while starting ActCAD
Clean Screen On/Off in the status bar to hide most UI items
Block Manager tool palette to manage Blocks between drawings
Many new commands like RESETUI, CUI, WSSAVE, GRADIENT etc.
Introduced new in-place Block Editor for easy block editing
New System Variable Manager to manage system variables
Several improvements to commands, features and performance
New Sketchmode option to enable Rotate, stretch and move
Import PCD Point Cloud Data (both Binary & ASCII)
New high resolution PDF Printer with Gradient Hatch Print support
Many new commands like AIDIMFILPARROW, TCASE, TEXTFIT, TJUST, DIM etc.

ActCAD 2020 Advantages

Economical : Very Low Life-time Price with full functions
No Special Learning : Familiar interface, commands & Icons
Best Performance : True power of 64bit & Multi-threading
Perpetual Licenses : Global Validity & Self-License Transfer
ActCAD Converter : Batch Auditing & File Conversions
All DWG & DXF versions : From R2 to 2018
PDF Support : 3D PDF Export, 2D PDF Import & Export
Raster to Vector : Image/Scanned Drawings to DXF Conversion
Express Tools & Add-on Features seo company in chennai
Fully Loaded : Almost close to other Expensive CAD Software
Content Management : Over 5000 Blocks included. Add your own too.
Many File Formats : DWG, DXF, DGN, DWF, SVG, PDF, OBJ, Images etc.

What Our Customers Saying

System Requirements

  • OS : Windows Vista, 7, 8, 8.1 & 10
  • CPU: Any CPU above 2GHz speed
  • Bit : 64bit/32bit
  • RAM : 3GB (higher RAM is better)
  • Hard Disk : 1GB free space

NOTE: Windows OS, mother board drivers, GPU drivers must be updated to latest versions for smooth functioning of ActCAD Software.

Free Technical Support

ActCAD has a dedicated Technical Support team to address the technical queries of its users. All queries will be answered either same working day or next working day. As developers, software testers and support people work together, solutions will be provided straight to the point with clear instructions and steps.
